Standing Desk Frame | Width 112 cm | White

Wall-mounted sit-stand frame, steel, in the color White. Width 112 cm. Stroke length 60 cm, height depends on mounting height. Effortless 40 kg lift.
Wall-mounted sit-stand frame, steel, in the color White. Width 112 cm. Stroke length 60 cm, height depends on mounting height. Effortless 40 kg lift.
Standing Desk Frame | Width 112 cm | White
Standing Desk Frame | Width 112 cm | White
Standing Desk Frame | Width 112 cm | White
$ 873
Item no.: 491-35 8W112

Frees up floor space. Fits anywhere. This dual-leg, wall-mounted adjustable desk frame offers maximum stability with zero footprint. It features an incredibly simple mounting system that only takes 31 min to assemble. Finished in RAL 9016 (white) with an 22-48" stroke, its dual legs easily handle a lifting capacity of 132 lbs. Ensuring certified ergonomic safety, the desk frame complies with ANSI/BIFMA G1-2013 across a 22.6”–48.7” height window designed for over 95% of users.

The desk frame is equipped with a digital controller featuring three memory presets, plus built-in collision and anti-tilt safety protection. The tactile buttons can easily be found by touch, making everyday operation simple without requiring visual attention.


Frame specifications

  • Frame width: 44.1"
  • Frame depth: 15.5"
  • Material/finish: Powdercoated steel RAL 9016 (white)
  • Height adjustment: 22-48"
  • Lifting capacity: 132 lbs
  • Operation: Included with the desk frame is a digital controller with three memory settings and built-in collision and anti-tilt protection. The tactile buttons ensure simple, intuitive, and safe operation.
  • Motor: ConSet’s tested and reliably operating 1-motor solution
Frame Color
White ▼
Frame Style
Add-Ons
No add-ons ▼
Control Unit
Frame color:
Frame size:
Detailed product information

Download 3D SAT and STEP files (ONLY AVAILABLE AT LOG-IN)
Download high resolution images (ONLY AVAILABLE AT LOG-IN)
Stock and components

A Product can consist of several components. Example: Multiple boxes: Top, Legs and cross beam support. Number, decription, Item number, weight, volume and price on the separate components is listed below.

Item no.:
491-35 8W112
Description:
Standing Desk Frame | Width 112 cm | White
Stock status
AmountItem no.DescriptionUnit pricePrice In stock
1XXX-X2 XWXXXLift column set, white$ 512,-$ 512,-
1501-39 XW400501-39 Arm Set, white$ 43,-$ 43,-
1501-X XWW02Wall mount, white$ 31,-$ 31,-
1501-XX 8XPOWSPower box S$ 205,-$ 205,-
1SQ137690Traversset, 112 cm, neutral$ 82,-$ 82,-

Total
$ 873,-
Component information
Item no.Length (cm)Width (cm)Height (cm)Weight (kg)EAN
XXX-X2 XWXXX77191715,005704142161616
501-39 XW40040752,205704142161692
501-X XWW02211372,005704142161647
501-XX 8XPOWS25971,005704142161876
SQ137690111532,305704142137697
